Tiger HP 6:1 Oil Pump with Bung Adapter

USD $1,449.00

44-1130-026
Balcrank Corporation
Made In The USA
Click to see additional Options / Models / Accessories Available
Options Accessories

Request a call



Click to view California Proposition 65 warning



The 6:1 ratio Tiger HP® pump can service as many as six simultaneous dispense points or transfer oil to distances up to 700 feet. Maximum simultaneous dispense points @ 1.5 gal/m (5.7 l/m) per dispense point. Note: pumping distance and pipe diameter will affect dispensing performance. The Tiger HP® air motor features a precision air valve mechanism with dual valve ports for improved high-speed breathing. It also contains a positive trip detent spool mechanism that eliminates stalling (blowing air) by preventing the pump from stopping between strokes. It has a simple yet durable construction with all internal parts lubricated at the factory using a life-tested synthetic grease. The Tiger HP® pumping assembly features a stainless pump rod for superior wear and corrosion resistance. The pump's exterior is constructed from aircraft-grade extruded aluminum for outstanding strength and reliability. The pump also has high-quality seals and is designed for long-term durability and ease of service. It is equipped with internal pressure relief to protect the system from thermal expansion.



Features

  • Operating air pressure range: 40–150 PSI (3–10 bar).
  • Pump delivery with SAE 10W30 oil, 68º F (20º C), 100 psi (7 bar) air pressure and free flow 16 gal/m (61 l/m).
  • Air consumption 100 psi (7 bar) and 8 gal/m (30 l/m) 59 SCFM.
  • Max fluid stall pressure @150 psi (10 bar) air 870 PSI (60 bar).
  • Wetted materials - Carbon steel, Buna-N™ Stainless steel, Nickel plated steel, Nylon, Ultrathane, and Viton.
  • 31 Cycles per Gal.
  • Air Inlet - 3/8” NPT (F).
  • Fluid Inlet - 1” NPT (F) 1-1/2” NPT (M).
  • Fluid Outlet - 3/4” NPT(F).
  • Effective Air Piston diameter - 3.2” (81 mm).



Technical

Dimensions (L x W x H) 25.72 H x 5.82 W inch
Power supply Air V/Hz/A
Weight approx. 39 lbs



Options

44-4410-056 Tiger Pump Hose Connecting Kit $172.00 Add to cart
44-4411-008 Wall Mount Bracket for LYNX, Panther HP and Tiger pumps $118.00 Add to cart



Accessories

44-3230-018 In-Line Hand Operated Valve for Air - 1/4" - 580 PSI $13.00 Add to cart
44-3230-019 In-Line Hand Operated Valve for Air - 3/8" - 580 PSI $17.00 Add to cart
44-3230-020 In-Line Hand Operated Valve for Air - 1/2" - 580 PSI $18.00 Add to cart
44-3230-021 In-Line Hand Operated Valve for Air - 3/4" - 580 PSI $23.00 Add to cart
44-3230-022 In-Line Hand Operated Valve for Air - 1" - 580 PSI $36.00 Add to cart
