Panther HP 3:1 Oil Pump with Bung Adapter

USD $770.00

44-1130-020
Balcrank Corporation
Made In The USA
Click to see additional Options / Models / Accessories Available
Options Accessories

Request a call



Click to view California Proposition 65 warning



The 3:1 ratio Panther® pump is suitable for simultaneous fluid distribution of up to five dispense points, or for pumping to distances of up to 500 feet. The Panther's air motor features a precision air reversing valve mechanism with dual valve ports for improved high speed breathing. It also contains a positive trip detent spool mechanism that eliminates stalling (blowing air) when the pump is caught between strokes. The Panther® pumping assembly features a nitrided steel pump rod and foot valve for superior wear and corrosion resistance. The pump's exterior is constructed from aircraft grade extruded aluminum for an outstanding strength-to weight ratio. The pump also has high quality Buna-N seals and is packaged in a pump that has proven reliable yet easy to service and maintain.



Features

  • Suitable for simultaneous fluid distribution of up to five dispense points, or for pumping to distances of up to 500 feet.
  • Pump delivery with SAE 10W-30 oil, 68º F, 100 PSI air pressure and free flow - 8 gal/m (30 l/m).
  • Air consumption (100 PSI and 4 G/M) 19.70 SCFM.
  • Max fluid stall pressure @150 PSI air 490 PSI (33.8 bar).
  • Wetted materials - Carbon steel, Buna-N™, stainless steel, nickel plated steel, nylon, ultrathane, zinc plated steel, and aluminum.
  • 34 Cycles per Gal
  • Effective air piston diameter 2.5" (63.5 mm)
  • Air inlet - 1/4" NPT (F)
  • Fluid inlet - 1" NPT (F), 1-1/2" NPT (M)
  • Fluid outlet - 3/4" NPT (F)



Technical

Weight approx. 20 lbs
Power supply Air V/Hz/A
Dimensions (L x W x H) 23-1/2 H inch



Options

44-1130-021 Panther 5:1 Pump with Bung Adapter - Oil $789.00 Add to cart
44-4410-054 Panther Pump Hose Connecting Kit $177.00 Add to cart
44-4411-008 Wall Mount Bracket for LYNX, Panther HP and Tiger pumps $118.00 Add to cart



Accessories

44-3230-018 In-Line Hand Operated Valve for Air - 1/4" - 580 PSI $13.00 Add to cart
44-3230-019 In-Line Hand Operated Valve for Air - 3/8" - 580 PSI $17.00 Add to cart
44-3230-020 In-Line Hand Operated Valve for Air - 1/2" - 580 PSI $18.00 Add to cart
44-3230-021 In-Line Hand Operated Valve for Air - 3/4" - 580 PSI $23.00 Add to cart
44-3230-022 In-Line Hand Operated Valve for Air - 1" - 580 PSI $36.00 Add to cart
44-4411-009N Aluminum bung adapter w/pressure relief for Panther HP & Tiger pumps $73.00 Add to cart
