Tire And Wheel Service



Tire Conveyor 15' Long

USD $17,738.00

713-001-01169MI
AME Automotive

Request a call



These tire conveyors are designed to move tires from passenger and light trucks up to or down from a mezzanine, with an incline as steep as 60 degrees. This conveyor is equipped with a control panel at both ends of the conveyor and an anchor plate made of steel for stability or can be secured to the floor. Installation is quick and comes with prewired electrical controls that plug into a outlet of 115 volts or 220 volts depending on the conveyor model. There are also cleats on the belt to ensure that a tire is held in place as it moves up or down the belt.



Features

  • Designed to carry tires up to or down from a mezzaninie, with an incline as steep as 60 degrees
  • Equipped with a control panel at both ends of the belt
  • Anchor plate made of steel at the bottom to ensure stability or it can be secure to the floor
  • Comes with prewired electrical controls that can be plugged into a 115 volt or 220 volt outlet
  • Features cleats to ensure tires stay in place on the belt as they move up or down
  • Tire Capacity is 12 minimuim



Technical

Tire width 21 inch
Wheel weight, max. 500 lbs
Weight approx. 750 lbs
Color Red
Power supply 120V, 6.5A, 750W, 1 Phase, 60HZ V/Hz/A
Dimensions (L x W x H) 180 x 21 x 11 inch
